Connector TNC High performance TNC coaxial connectors with thread coupling for vibration environment, Mainly used for Cellular Mobile Phones, Aviation Controls, Telemetry, Bluetooth and GPS, Wireless Base Station, Microwave Components, Radar, Networks, Antenna Mounts, Machine to machine communications, Security Devices, Instrumentation.
TNC(Threaded Neil Concealment) connector emerged in 1956 as an alternative to the bayonet coupling mechanism of BNC. Which have the same basic structural parameters as BNC connector.
*Made according to MIL-C-39012 standard.
*Thread Version of BNC used in Vibration-Intense application;
*Higher Performance with 0-11 GHz frequency and 50 ohm impedance
Frequency Range: 0~11GHz
VSWR: Straight type ≦ 1.3max / R/A type ≦ 1.5max
Dielectric Withstanding Voltage: 1500 V rms
Working Voltage: 500 V rms
Center Contact Resistance ≦ 3.0 mΩ (Milliohms max.)
Outer Contact Resistance ≦ 2.0 mΩ (Milliohms max.)
Insulation Resistance ≧5 × 10³ mΩ (Milliohms min.)
Coupling: 7/16-28 thread
Contact Retention: 6 lbs min.
Mating Durability: ≧500 cycles
Temperature: Teflon -55oC~+155oC / POM -40oC~+60oC
Coupling Nut Retention: 100 lbs. min.
Vibration: MIL-STD-202 Meth. 204
Corrosion Resistance: MIL-STD-202 Meth. 101
